Pcb Relay 24vdc
Pcb Relay 24vdc

Pcb Relay 24vdc

Features

1. 5mm thickness,up to 6A breaking capacity.

2. Conformity with RoHs directive.

3. Wide choice of sockets available covering a range of voltagesfrom 3 to 230V.

4. This product has excellent performance and has passed UL, CE, and certification. FAQ 1. What are your advantages?…

certificate Request A Quote

Share Our Social

Product Details

1. 5mm thickness,up to 6A breaking capacity.

2. Conformity with RoHs directive.

3. Wide choice of sockets available covering a range of voltagesfrom 3 to 230V.

4. This product has excellent performance and has passed UL, CE, and certification.

11 22

FAQ:

1: What are your advantages?
A: We have a professional development, marketing and production team to provide you with the most competitive prices and the best service.

2: What is your main product?
A: We focus on the development and production of multiple types of relays.3 What ls your warranty tlme of the products?

3: What’s your payment term?4 How to proceed an order for relay?
A: We usually accept T/T(100%).

4: Would you accept to use our logo?
A:lf you have good quantity,we can make OEM for you.



Automotive micro relay appliance

RKE4CO

Our workshops have clean control, dust free, constant temperature and humidity. Everyone should on the anti-static clothes when enter workshop.

Characteristics

Contact Configuration 1A, 1C
Load / Resistance 6A/250VAC 30VDC
Switching capacity (resistive) 1500VA, 180W
lnitial contact resistance ≤100mΩ(gold plated contact ≤30mΩ)
Material Ag alloy
Electrical durability NO: 6 x 104/NC: 3×104 times (1800 Ops/h)
Mechanical durability ≥2 x 107 (18000 Ops/h)
Pick-up voltage (23℃) DC:<75%(Rated voltage)
Drop-out voltage (23℃) DC:≥5% (Rated voltage)
Maximum voltage (23℃) 110% (Rated voltage)
Insulation resistance ≥1000MΩ (500VDC)
coil operating power 3~24 VDC approx.0.17W
48~60 VDc approx.0.21W
Operate time (at nominal voltage) ≤8ms
Release time (at nominal voltage) ≤4ms
lnitial breakdown voltage Between open contacts 1000VAC/1min (leakage current 1mA)
Between contacts and coil 4000VAC/1min (leakage current 1mA)
Ambient temperature -40~+85℃
Humidity 5%~85%RH
Air pressure 86~106KPa
Shock resistance 10G (half-sine shock pulse: 11ms)
Vibration resistance 10~55Hz double-amplitude:1.0mm
Mounting PCB
Unit weight 6g

3

5
