4181 PCB Power Relay
4181 PCB Power Relay

4181 PCB Power Relay

Features

Small size,low power consumption·Application ,motor load.

certificate Request A Quote

Share Our Social

FAQ:

1: What the advantage of your products ?
A: We use the first class plastic , and brass to the products , and produce it by the whole automatic machine.

2: Can I get the sample? Pay or not?
A: The sample is free ,you didn’t pay for it.

3: What are the common sizes of your products ?
A: It is internal size , the same as Omron relay.

4: Why do we need pay attention to use the relay?
A: You just follow the rate that we written on the catalogue , it will be no problem.



Characteristics

Contact Contact form 1C
Rated Load(Ac-1) 6A/14VA, 15A/14VDC
Operating power(Resistive) 84W, 210W
Contact resistance(Initial) ≤100mΩ
Material Ag alloy
Electrical life ≥105 cycles(1800 Ops/h)
Mechanical life ≥107 cycles(1800 Ops/h)
Operate voltage(at 25℃) ≤60%(rated voltage)
Release voltage(at 25℃) ≥10% (rated voltage)
Max.Allowed voltago(at 25℃) 3~24VDC
Insulation resistance ≥100MΩ (50OVDC)
Coll power consumption DC (W) 0.6W, 0.36W
Operate time (at nominal voltage) ≤10ms
Release time (at nominal voltage) ≤5ms
Dlelectrio Strength Between contacts 500VAC/1min (leakage current 1mA)
Between contacts and coil 500VAC/1min (leakage current 1mA)
Ambient temperature -30~+85℃(Use), -40~+100℃(store)
Shock resistance Functional 10G, Destructive 100G
Vibration resistance 10~55Hz double-amplitude: 1.5mm
Install model solder mount
Terminal PCB terminal
Weight Approx.15g
