32F PCB Power Relay
32F PCB Power Relay

32F PCB Power Relay

Features

Small size,low power consumption•Application air-condition,industrial control circuit etc.

certificate Request A Quote

Share Our Social



FAQ:

1: How do you shipping?
A: FOB Nanjing or CIF.

2: What should I do if the quality is damaged?
A: If there is any damage, the customer can confirm it with a photo, and once it is free, it will not be free or the damage will be reduced.

3: Are you manufacture or trading company?
A: We are manufacture and we invite customer from all over the world come to visit us.

4: How to ship the order to us?
A: If the order quantity is small, we suggest to ship them by air express DHL, FEDEX or UPS etc.



Characteristics

Contact Contact form 1A 1B 1C
Rated Load(Ac-1) 5A/250VAC 30VDC
Operating power(Resistive) 1250A, 150W
Contact resistance(Initial) ≤50mΩ
Material Ag alloy
Electrical life ≥105 cycles(1800 Ops/h)
Mechanical life ≥107 cycles(18000 Ops/h)
Operate voltage(at 25℃) ≤75%(rated voltage)
Release voltage(at 25℃) ≥10% (rated voltage)
Max.Allowed voltago(at 25℃) 110% (Rated voltage)
Insulation resistance ≥100MΩ (50OVDC)
Coll power consumption DC (W) 0.45, 0.36
Operate time (at nominal voltage) ≤10ms
Release time (at nominal voltage) ≤5ms
Dlelectrio Strength Between contacts 750VAC/1min (leakage current 1mA)
Between contacts(different pole)
Between contacts and coil 1500VAC/1min (leakage current 1mA)
Ambient temperature -25~+55℃
Humidity 35%~85%RH
Air pressure 86~106KPa
Shock resistance 10G(half-sine shock pulse: 11ms)
Vibration resistance 10~55Hz double-amplitude: 1.5mm
Install model PCB terminal
Weight Approx.7g
