14FL PCB Power Relay
14FL PCB Power Relay

14FL PCB Power Relay


Small size,high power capacity•Application;telecommunication equipment.

certificate Request A Quote

Share Our Social



1: Did you export to my location?
A: We have been exporting worldwide more than 30 countries.

2: Where are you company? Could visit to you company?
A: Add: No.666 East jiaotong Rd,wenzhou bridge, Baixiang, Yueqing, Zhejiang, China 325603

3: What your main products?
A: We have relay, relay base ,and accessories.

4: Do you have new products notice ?
A: Yes, if have new products , we will update our website and sent email to all my customer.



Contact Configuration 1A, 1B, 1C 2AS, 2BS, 2CS
Rated Load(Ac-1) 10A/120VAC,30VDC 15A/120VAC, 30VDC
Operating power(Resistive) 1200VA, 300W 1800VA, 450W
Contact resistance(Initial) ≤50mΩ
Material Ag alloy
Electrical life 1 × 105 cycles(1800 Ops/h)
Mechanical life 1 × 107 cycles(1800 Ops/h)
Operate voltage(at 25℃) ≤75%(rated voltage)
Release voltage(at 25℃) ≥10% (rated voltage)
Max.Allowed voltago(at 25℃) 110% (Rated voltage)
Insulation resistance ≥100MΩ (50OVDC)
Coll power consumption DC (W) 1.1
Operate time (at nominal voltage) ≤3ms
Release time (at nominal voltage) ≤1.50ms
Dlelectrio Strength Between contacts 500VAC/1min (leakage current 1mA)
Between contacts and coil 500VAC/1min (leakage current 1mA)
Ambient temperature -25~+55℃
Humidity 35%~82%RH
Air pressure 86~106KPa
Shock resistance 10G(half-sine shock pulse: 11ms)
Vibration resistance 10~55Hz double-amplitude: 1.0mm
Install model PCB
Weight 12g,24g
