14FF PCB Power Relay
14FF PCB Power Relay

14FF PCB Power Relay


Miniature size,high switching capacity,high sensltivity

certificate Request A Quote

Share Our Social


1: In what environment can be use for relay ?
A: We have a special relay, is waterproof ,oil-proof , dust-proof, it can be use the bad environment.

2: Can you tell me the application area?
A: Used in machinery, manufacturing, hoisting machinery, machine tools, paper-making equipment, printing and packing ,elevators, robots and so on

3: What if you’re out of stock?
A: We are manufacturers and can do overtime if you need large quantities of purchases.

4: What material of the contact ?
A: Almost the contacts is Sliver alloy , but few is use gold plated.


Automotive micro relay appliance


Our workshops have clean control, dust free, constant temperature and humidity. Everyone should on the anti-static clothes when enter workshop.



Contact Configuration 1A, 1B, 1C 2A, 2B, 2C
Rated Load Resistive load (Ac-1) 10A/250VAC,30VDC 5A/250VAC, 30VDC
Motor load (Ac-15) 1/3HP,120VAC; 1/2HP,240VAC 1/6HP,240VAC;1/3HP,240VAC
Operating power(Resistive) 2500VA, 300W 1250VA, 150W
Contact resistance(Initial) ≤50mΩ
Material Ag alloy
Electrical life ≥105 cycles(1800 Ops/h)
Mechanical life ≥107 cycles(1800 Ops/h)
Operate voltage(at 25℃) DC: ≤75%(rated voltage)
Release voltage(at 25℃) DC: ≥10% (rated voltage)
Max.Allowed voltago(at 25℃) 110% (Rated voltage)
Insulation resistance ≥1000MΩ (50OVDC)
Coll power consumption DC (W) approx. 0.53
Operate time (at nominal voltage) ≤20ms
Release time (at nominal voltage) ≤10ms
Dlelectrio Strength Between open contacts 1000VAC/1min (leakage current 1mA)
Between contacts(different pole) 1000VAC/1min (leakage current 1mA)
Between contacts and coil 5000VAC/1min (leakage current 1mA)
Ambient temperature -40~+70℃
Humidity 35%~85%RH
Air pressure 86~106KPa
Shock resistance 10G(half-sine shock pulse: 11ms)
vibration resistance 10~55Hz double-amplitude: 1.0mm
Mounting PCB
Unit weight Approx.17g
Matched relay socket SRB05-E SRCO5-E SRC05-P SRB08-E SRC08-E SRC08-P
Like products G2R
