11 Pin Timer Relay
11 Pin Timer Relay

11 Pin Timer Relay

Features

10pcs/tray, 180pcs/cartons, carton size: 40*30*15cm, 24cartons a pallet
High-strength cartons, good for long-distance export transport

certificate Request A Quote

Share Our Social

Product Information

Adjustable Delay Timer Relay Details

TKB Ordering Information
TKB22

FAQ：

1: What’s the shipping way?
A: We usually send your goods by air express, such as DHL, UPS, TNT etc.

2: How to get the sample?
A: We can provide sample to you for free if you are willing to undertake shipping cost. If you need sample, please contact us directly, we will calculate the shipping cost for you soon.

3: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the free sample but exclude.

4: I wonder if you accept small orders?
A: Please fell free to contact us no matter how many products you want, we will try our best to get the best price for you.



Characteristics

Characteristics

Models TKB2B TKB4B
Rated supply voltage 120VAC, 230VAC 50/60Hz; DC24V
Operating voltage range Rated voltage 85-110% (90%-110% is DC12V)
Power consumption 3.5W
Max. output load 5A, 250 VAC (p.f.=1) 3A, 250 VAC (p.f.=1)
Min. output load 10 mA, 17 VDC
Repetitive error ±2% (FS max.)
Setting error ±5% (FS max.)
Voltage error ±2% (FS max.)
Temperature error ±2% (FS max.)
Resetting time Min. time: 0.2 sec
Insulation resistance 100MΩ (DC500V)
Dielectric strength Between current-carrying and Non-current-carrying parts 2000V 50/60Hz min
Between control output terminals and operating circuit1500V 50/60Hz min
Between contacts 1000V 50/60Hz min
Vibration resistance Destruction 10~55Hz with 0.75mm single amplitude each in 3directions for 2 hours each
Malfunction 10~55Hz with 0.5mm single amplitude each in 3 directions for 10 minutes each
Shock resistance Destruction 30G
Malfunction 10G
Ambient temperature -10ºC~55ºC
Ambient humidity 35%~85%RH
Life expectancy Mechanical ＞107 (under no load, at 1,800 operations/hour)
Electrical ＞105
Weight Approx. 60g

Specifications

Up/Down Selectable Type

TKB2

Dimensions (mm)

Adjustable Delay Timer Relay Dimensions (mm)

TKB3
